Agro Fossil Free - Energy-based performance analysis of a double pass solar air collector integrated to triangular shaped fins

General Description

In this paper, the performance of a double pass solar air collector with triangular integrated fins was investigated experimentally at Hungarian University of Agriculture and Life Sciences in Gödöllő, Hungary. The focus of this research is on energy-based performance evaluation. The thermal efficiency of the collector has been compared by testing two collectors that had the same design, with and without fins. The effect of the collector's air mass flow rate on thermal performance was investigated under various environmental situations. The results revealed that the temperature difference is always higher through the finned collector and the higher variation temperature between the inlet and outlet temperature leads to higher useful heat. The daily thermal efficiency of the finned collector was 56.57%, 59.41%, and 61.42%, while for the un-finned collector was 51.04%, 53.28%, and 57.08% for the mass flow rate 0.0081, 0.0101, and 0.0121 kg/s. The finned double pass solar air collector improved the thermal efficiency by 4.3–6.1% over the un-finned one. The efficiency of the finned collector is always higher than the un-finned one regardless of the mass flow rate. The presence of the fins to the top air channels significantly increases collector efficiency, owing to the increased absorbing surface area, which is responsible for increasing the internal thermal convective exchanges. Moreover, it creates a turbulence airflow, meaning that the air will be in good contact with the absorber plate and penetrate all regions, reducing the dead zones contributing to increased heat transfer.
